PD1473 SERIES SERVICE BRAKE

PD1473 SERIES SERVICE BRAKE

The Carlisle Brake & Friction PD1473 Series Service Brake is a hydraulically actuated, single opposed piston, caliper disc brake, designed to provide medium torque ranges for moderate to severe service conditions. Both the caliper and disc require fixed mountings. Multiple calipers may be used on a single disc to proportionately increase torque output. This brake is also available with retracting springs and automatic adjusters, ideal for high speed applications.

Additional Product Details

  • Flexible mounting alternatives to accommodate numerous equipment types
  • Constructed from ductile iron casting for superior brake durability
  • Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
  • Optional seal materials available for compatibility with all actuation fluids and temperatures
  • Electroless nickel plated housing for corrosive environments available on auto-adjust model

Technical Specifications

Caliper Material High-strength ductile iron
Disc Diameter Range Unlimited
Disc Thickness Unlimited
Inlet Type .125-27 NPTF
Lining Area per Brake 9.6 in² / 61.94 cm²
Maximum Pressure 1500 psi / 103.42 bar
Minimum Pressure 0 psi / 0 bar
Mounting Attitude 3, 6, 9, 12 o’clock
Number of Pistons 2
Assembly Weight 16 lbs / 7.26 kg
