PD1240 SERIES SERVICE BRAKE

PD1240 SERIES SERVICE BRAKE

The Carlisle Brake & Friction PD1240 Series Service Brake is a hydraulically actuated, three piston disc brake. This brake requires a fixed mounting with an axially floating disc.

Additional Product Details

  • Flexible mounting alternatives to accommodate numerous vehicle types
  • Constructed from ductile iron casting for superior brake durability
  • Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
  • Utilizes EPR seals for use with SAE J1703 automotive brake fluid
  • Compact space claim



Technical Specifications

Assembly Weight 5 lbs / 2.27 kg
Caliper Material High-strength ductile iron
Disc Diameter Range 9.12 in (231.6 mm)
Disc Thickness .718 in (18.2 mm)
Inlet Type .500-20 UNF
Lining Area per Brake 9.13 in² / 58.9 cm²
Maximum Pressure 1400 psi / 96.53 bar
Mounting Attitude 3, 9 o’clock
Number of Pistons 3
