SCL13 SERIES SERVICE BRAKE

The Carlisle Brake & Friction SCL13 Series Service Brake is a hydraulically actuated, single opposed piston, caliper disc brake, designed to provide medium torque ranges for moderate to severe service conditions. Both the caliper and disc require fixed mountings. Multiple calipers may be used on a single disc to proportionately increase torque output.

Additional Product Details

Flexible mounting alternatives to accommodate numerous equipment types
Constructed from ductile iron casting for superior brake durability
Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
Optional seal materials available for compatibility with all actuation fluids and temperatures

Technical Specifications

Caliper Material	High-strength ductile iron
Disc Diameter Range	12 in (304.8 mm) to unlimited
Disc Thickness	0.5 in / 12.7 mm
Displacement per Brake	.23 in³ (4.1 cm³)
Inlet Type	.125-27 NPTF
Lining Area per Brake	9.6 in² / 61.94 cm²
Maximum Pressure	1500 psi / 103.42 bar
Mounting Attitude	3, 9, 12 o’clock
Number of Pistons	2
Assembly Weight	13 lbs / 5.9 kg
