PD1428 SERIES SERVICE BRAKE

PD1428 SERIES SERVICE BRAKE

The Carlisle Brake & Friction PD1428 Series Service Brake is a hydraulically actuated, single opposed piston, caliper disc brake with retracting springs and automatic adjusters. Both the caliper and disc require fixed mountings. This brake provides heavy-duty braking ideal for high speed applications. Multiple calipers may be used on a single disc to proportionately increase torque output.

Additional Product Details

  • Flexible mounting alternatives to accommodate numerous equipment types
  • Constructed from ductile iron casting for superior brake durability
  • Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
  • Optional seal materials available for compatibility with all actuation fluids and temperatures

Technical Specifications

Caliper Material High-strength ductile iron
Disc Diameter Range Unlimited
Disc Thickness Unlimited
Displacement per Brake 1.8 in³ (29.5 cm³)
Inlet Type .250-18 NPTF
Lining Area per Brake 24.8 in² / 160 cm²
Maximum Pressure 1350 psi / 93.08 bar
Minimum Pressure 30 psi / 2.07 bar
Mounting Attitude 3, 6, 9, 12 o’clock
Number of Pistons 2
Assembly Weight 22 lbs / 9.98 kg
