PD1182 SERIES SERVICE BRAKE

PD1182 SERIES SERVICE BRAKE

The Carlisle Brake & Friction PD1182 Series Service Brake is a hydraulically actuated, single opposed piston, caliper disc brake designed for medium-duty dynamic or static applications. Both the caliper and disc require fixed mountings. Multiple calipers may be used on a single disc to proportionately increase torque output. This brake is also available with automatic adjusters which maintain a fixed disc to lining clearance.

Additional Product Details

  • Flexible mounting alternatives to accommodate numerous equipment types
  • Constructed from aluminum casting for light weight
  • Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
  • Optional seal materials available for compatibility with all actuation fluids and temperatures

Technical Specifications

Assembly Weight 11 lbs / 4.99 kg
Caliper Material Aluminum
Disc Diameter Range 10 in (254 mm) to unlimited
Disc Thickness .625 in (15.9 mm) to unlimited
Displacement per Brake .36 in³ (5.9 cm³)
Inlet Type .4375-20 UNF
Lining Area per Brake 12.7 in² / 81.94 cm²
Maximum Pressure 1500 psi / 103.42 bar
Minimum Pressure 0 psi / 0 bar
Mounting Attitude 6, 12 o’clock
Number of Pistons 2
