M6-29 SERIES SERVICE BRAKE

M6-29 SERIES SERVICE BRAKE

The Carlisle Brake & Friction M6-29 Series Service Brakes are hydraulically actuated, six-piston, caliper disc brakes designed for a variety of dynamic braking requirements. These brakes are typically mounted to a flange on the vehicle’s axle or mounting bracket for service brake applications.

Additional Product Details

  • Flexible mounting alternatives to accommodate numerous vehicle types
  • Constructed from ductile iron casting for superior brake durability
  • Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
  • Optional seal materials available for compatibility with all actuation fluids and temperatures
  • Open caliper provides easy access for visual inspection and serviceability
  • For a design option with piston retractors, specify part number 419-8955, for design options without piston retractors, specify 419-8132

Technical Specifications

Caliper Material High-strength ductile iron
Disc Diameter Range 26.0 in to 30.0 in (660.4 mm to 762.0 mm)
Disc Thickness 0.75 in / 19.05 mm
Displacement per Brake 1.5 in³ (24.6 cm³)
Lining Area per Brake 108 in² / 696.77 cm²
Lining Material Carlisle premium asbestos-free
Maximum Pressure 2300 psi / 158.58 bar
Mounting Attitude 3, 9 o’clock
Number of Pistons 6
Final Assembly Weight 156.2 lbs / 70.85 kg

Recommended Related Products

Normal Brake Usage
Brake Location
Actuation


Actuation Fluid
All gear reduction between the brake location and the vehicle ground contact.
2% standard unless otherwise specified.
Maximum pressure available at brake input.
Dynamic (Rdvn)
0% will be used unless otherwise specified.
0.5 is typical ground coefficient for unmaintained loose earth.
