C2 SERIES SERVICE BRAKE

C2 SERIES SERVICE BRAKE

The Carlisle Brake & Friction C2 Series Service Brake is a hydraulically applied, two-piston brake with retracting springs and automatic adjusters. This brake is typically mounted on the vehicle’s drive shaft for service brake applications.

Additional Product Details

  • Flexible mounting alternatives to accommodate numerous vehicle types
  • Constructed from ductile iron casting for superior brake durability
  • Equipped with Carlisle premium asbestos-free linings, providing  superior stopping performance and life
  • Optional seal materials available for compatibility with all actuation fluids and temperatures
  • Open caliper provides easy access for visual inspection and serviceability



Technical Specifications

Caliper Material High-strength aluminum
Disc Diameter Range 10.0 in (254.0 mm) to unlimited
Disc Thickness 0.5 in / 12.7 mm
Lining Area per Brake 16 in² / 103.23 cm²
Lining Material Carlisle premium asbestos-free
Maximum Pressure 1000 psi / 68.95 bar
Mounting Attitude 3, 9 o’clock
Number of Pistons 2
Final Assembly Weight 13 lbs / 5.9 kg

Recommended Related Products

Normal Brake Usage
Brake Location
Actuation


Actuation Fluid
All gear reduction between the brake location and the vehicle ground contact.
2% standard unless otherwise specified.
Maximum pressure available at brake input.
Dynamic (Rdvn)
0% will be used unless otherwise specified.
0.5 is typical ground coefficient for unmaintained loose earth.
