RT SERIES PARK BRAKE

The Carlisle Brake & Friction RT Series Park Brake, is a mechanically actuated, sliding caliper brake, designed for static/secondary applications. Please contact Carlisle regarding dynamic braking applications.

Additional Product Details

Ideal for parking, secondary and industrial braking needs
Ductile iron casting for high strength
Quick-change non-asbestos organic or sintered metallic linings
Less fade in emergency situations than brake drums
Open caliper provides easy access for visual inspection, serviceability and lower maintenance costs
Lining retraction springs reduce parasitic drag
Actuation lever may be indexed at 60° intervals
Brake can be supplied with mounting hardware

Technical Specifications

Caliper Material	High-strength ductile iron
Disc Diameter Range	8.0 in to 20.0 in (203.2 mm to 508.0 mm)
Disc Thickness	0.31 in to 0.5 in (7.9 mm to 12.7 mm)
Final Assembly Weight	7 lbs / 3.18 kg
Lining Area per Brake	9.55 in² / 61.61 cm²

Recommended Related Products

SA7 SERIES PARK BRAKE
- View Product Details
MODIFIED RT SERIES PARK BRAKE
- View Product Details
SAHR RT SERIES PARK BRAKE
