FSH SERIES COMBINATION PARK & SERVICE BRAKE

FSH SERIES COMBINATION PARK & SERVICE BRAKE

The Carlisle Brake & Friction FSH Series Brake features two internal floating shoes with hydraulic cylinder actuation, drum brake. Carlisle FSH brakes can be supplied with an optional mechanical parking brake and automatic or manual brake adjustments.

Additional Product Details

  • Mechanical hand brake available
  • Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
  • Optional seal materials available for compatibility with all actuation fluids and temperatures

Technical Specifications

Brake Size 8" to 12 1/2"
Lining Material 3/16" to 1/4" thick bonded linings
Wheel Cylinder Diameter 7/8" to 1 1/2" cylinder sizes
Comments Shoe widths: 11/4" to 2 1/4"

Recommended Related Products

  • HDBC SERIES COMBINATION PARK & SERVICE BRAKE
    HDBC SERIES COMBINATION PARK & SERVICE BRAKE
    • View Product Details
  • DSH SERIES PARK & SERVICE BRAKE
    DSH SERIES PARK & SERVICE BRAKE
    • View Product Details
  • SCL8 SERIES COMBINATION PARK & SERVICE BRAKE
    SCL8 SERIES COMBINATION PARK & SERVICE BRAKE
    • View Product Details
Normal Brake Usage

Brake Location

Actuation


Actuation Fluid


All gear reduction between the brake location and the vehicle ground contact.
2% standard unless otherwise specified.
Maximum pressure available at brake input.
Dynamic (Rdvn)
0% will be used unless otherwise specified.
0.5 is typical ground coefficient for unmaintained loose earth.
